Are you a Diesel engine fan? Are you looking for more power? Yeah, we know that feeling!  MuchBoost.com would like to present the summary of all Hybrids and Big Turbochargers for VAG diesel engines of all sorts.

When it comes to the other diesel engines from Opel, Fiat, Citroen, Mercedes, etc we are able to do the same upgrades but only with vacuum or electronic actuator adaptation (conversion), without a welded manifold.

Feel free to look into the list and search for anything you may need.

Turbo Nomenclature

What do turbo markings mean?

Let’s take for example a GTB2056VK.

GTB stands for Garrett Turbo

20 refers to the frame size of the turbo, it is connected with the turbine wheel

56 refers to the compressor exducer size in millimeters, in this case, the compressor wheel is 56mm in diameter.

VK means that there are “standard” journal bearings used in this turbo, sometimes you may find VRK or VKLR, which means that ball bearings have been used for those turbos. L means that the turbo is water-cooled as well.

We decided to split our Hybrid Turbos into two categories. First, there are the Plug&Play turbos for the transverse & longitudinal 1.6/1.9/2.0 TDI engines which mainly require an ECU Tune after installation.  Turbos below are listed in ascending power numbers.

1.9TDI 1Z AHU ALE with an estimated potential of 130-160HP.

1Z AHU ALE Hybrid Turbo Upgrade 1.9TDI VW Golf MK3 / MK4, Passat B5, AUDI A4 B5, A6 C4

GTC1246VZ with an estimated potential of 160HP at 24PSI.

GTC1246VZ Hybrid Turbo Upgrade CLNA, CAYA, CAYB, CAYC

GT1749V with an estimated potential of 180HP at 25PSI.

GT1749V Hybrid Turbo Upgrade VAG Audi, Seat, Skoda, Volkswagen 1.9/2.0 TDI Manifold

GT1752V with an estimated potential of 200HP at 26PSI

GT1752V Hybrid Turbo Upgrade 1.9/2.0 TDI VAG Audi, Seat, Skoda, VW

AWX hybrid turbocharger with an estimated potential of 210HP at 28PSI.

GT1752V 1.9/2.0TDI Hybrid Turbo Upgrade AFV, AWX, BPW, BGW, BLB

2.0TDI CKR with an estimated potential of 220HP.

CKR 2.0TDI Hybrid Turbo Upgrade Volkswagen Passat B7, Seat Ibiza V

2.0TDI CR KKK with an estimated potential of 220HP at 27-28PSI.

2.0TDI CR Hybrid Turbo Upgrade KKK Audi A3, Skoda Yeti, VW Eeos, Golf, Passat, Scirocco

2.0TDI CR CFHC, CFHD with an estimated potential of 220HP at 27-28PSI.

2.0TDI CR CFHC, CFHD Hybrid Turbo Upgrade Audi A1, Seat Altea, Seat Ibiza, Octavia, VW Passat, Scirocco, Touran

GT1756V with an estimated potential of 220-230HP at 30-32PSI.

GT1756V Hybrid Turbo Upgrade Billet Wheel 1.9/2.0TDI Audi, Seat, Skoda, VAG

2.0TDI CAGA with an estimated potential of 220-230HP.

CAGA Hybrid Turbo Upgrade 2.0TDI Audi A4 B8/A5 8T/A6 C6/Q5 8R, Seat Exeo

VNT17/20 with an estimated potential of 220-230HP at 30-32PSI.

VNT17/20 1.9/2.0TDI Garrett Hybrid Turbo Upgrade Billet Wheel Audi, Seat, Skoda, VW

BRD 2.0TDI with and estimated potential of 230HP.

BRD 2.0TDI Hybrid Turbo Upgrade Audi A4 B7

CAHA 2.0TDI with an estimated potential of 230HP at 28-29PSI.

CAHA Hybrid Turbo Upgrade CGLB 2.0TDI Audi A5, A6, Q5, Seat Exeo

2.0TDI CGLC with an estimated potential of 230HP at 27-28PSI.

2.0TDI CGLC Hybrid Turbo Upgrade Audi A4, A5, A6 GTC1549VZ

2.0TDI BMN/BMR/BUY/BUZ with an estimated potential of 230-260HP at 30-32PSI.

2.0TDI Hybrid Turbo Upgrade BMN, BMR, BUY, BUZ

2.0TDI BMM/BMP/BVD with an estimated potential of 230-260HP at 30-32PSI

2.0TDI Hybrid Turbo Upgrade BMM, BMP, BVD

2.0TDI CR CKF, CKFC, CRMB with an estimated potential of 240HP at 27-28PSI.

2.0TDI Hybrid Turbo Upgrade CKF, CKFC, CRMB

2.0TDI CR CUUA, CUUB with an estimated potential of 240HP at 27-28PSI.

2.0TDI Hybrid Turbo Upgrade CUUA, CUUB VW Scirocco, Skoda Yeti

2.0TDI CR IHI CRLB with an estimated potential of 240HP at 27-28PSI.

2.0TDI IHI Hybrid Turbo Upgrade Audi A3 8V, VW Golf VII CRBC, CRLB, CRBB

EA288 Evo2 2.0TDI with an estimated potential of 260HP.

EA288 Evo2 VW Golf 8 GTD 2.0TDI Hybrid Turbo Upgrade Arteon, Passat B8, Audi A4 B9, A5 9T, A6 C8, Skoda Octvia IV, Superb III

DSUD 2.0TDI with an estimated potential of 250HP.

DSUD 2.0TDI Hybrid Turbo Upgrade Volkswagen Golf VIII

VNT18/20 GT1856V with an estimated potential of 250-260HP at 30-32PSI.

BIG SHELL 1.9TDI VNT18/20 Upgraded Hybrid Turbocharger GT1856V 2.0TDI

EA288 2.0TDI with an estimated potential of 260HP.

EA288 2.0TDI Hybrid Turbo Upgrade Audi A4 B8, A5 8T, A6 C7, VW Arteon, Passat B8, Skoda Superb III, Seat Ateca CNHA, DETA

2.0TDI CR CB Series with an estimated potential of 260HP at 23PSI.

2.0TDI CR Hybrid Turbo Upgrade CBDB, CBDA, CBAB, CBAA, Audi A3 8P, VW Golf MK V/VI, Passat B6

2.0TDI CUNA CUPA GTD1449VZ with an estimated potential of 260HP at 29PSI.

2.0TDI CUNA Hybrid Turbo Upgrade CUPA GTD1449VZ Golf VII GTD, Seat Leon 5F, Audi A3 8V, Skoda Octavia III

VNT18/20 GT1860V with an estimated potential of 260-280HP at 32-34PSI.

VNT18/20 BIG SHELL Upgraded Hybrid Turbocharger GT1860V 1.9/2.0TDI

CFCA 2.0BiTDI with an estimated potential of 300-330HP.

2.0BiTDI CFCA Hybrid BiTurbo Upgrade Volkswagen Amarok I, Transporter T5

CUAA 2.0BiTDI with an estimated potential of 400-450HP.

CUAA 2.0BiTDI Hybrid Turbo Upgrade VW Passat B8, Arteon, Tiguan II, Skoda Kodiaq RS

Now, let’s move to the BIG TDI Turbos that require some additional work done, list of things needed to be done is mentioned on the product page.

GTD1752VRK with an estimated potential of 230HP at 28PSI.

Billet Wheel GTD1752VRK vacuum converted with welded 1.6/1.9/2.0 TDI manifold

GTD1756VRK with an estimated potential of 240-250HP at 29-30PSI.

Billet Wheel GTD1756VRK Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB1756VK with an estimated potential of 240-260HP at 32-34PSI.

Billet Wheel GTB1756VK Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2056VK with an estimated potential of 250-270HP at 33-35PSI.

1.9TDI GTB2056VK Big Turbo Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2060VK with an estimated potential of 260-280HP at 34-36PSI.

GTB2060VK Big Turbo 1.9TDI Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTD1960VKR with an estimated potential of 270-280HP at 30-31PSI.

Billet Wheel GTD1960VRK Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2060VKLR with an estimated potential of 270-280HP at 34-36PSI.

Billet Wheel GTB2060VKLR Ceramic Ball Bearing Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2062VKLR with an estimated potential of 290HP at 36PSI.

GTB2062VKLR Ball Bearing Hybrid Turbo vacuum converted and welded onto stock 1.9 2.0TDI

GTB2260VK with an estimated potential of 290-310HP at 35-37PSI.

Billet Wheel GTB2260VK BigTurbo Upgrade TDI vacuum converted with a welded 1.9/2.0 TDI Manifold

GTD2060VRK with an estimated potential of 310HP at 33PSI.

GTD2060VRK Ball Bearing Hybrid Turbo Upgrade adapted to 1.9/2.0TDI Common Rail

GTB2260VKLR with an estimated potential of 300-320HP at 35-37PSI.

1.9TDI GTB2260VKLR Ceramic Ball Bearing Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2262VKLR with an estimated potential of 320HP at 38PSI.

GTB2262VKLR 1.9TDI Ball Bearing Hybrid Turbo vacuum converted with a welded 1.9/2.0 TDI Manifold

GTD2060VZ with an estimated potential of 333HP at 33PSI.

GTD2060VZ 1.9TDI Vacuum Converted Hybrid Turbo Upgrade with 1.9/2.0TDI Manifold

GTB2265VKLR with an estimated potential of 320-340HP at 36-38PSI.

Billet Wheel GTB2265VKLR Ceramic Ball Bearing Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2265VK with an estimated potential of 340-350HP at 36-38PSI.

Billet Wheel GTB2265VK Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTD2260VZ with an estimated potential of 360HP.

GTD2260VZ Hybrid Turbo Upgrade adapted to fit 1.9/2.0TDI engines

GTD2265VKLR with an estimated potential of 360HP.

GTD2265VRK Ball Bearing Hybrid Turbo Upgrade adapted to 1.9/2.0TDI Common Rail

GTD2265VZ with an estimated potential of 366HP.

GTD2265VZ 1.9TDI/2.0TDI Vacuum Converted Hybrid Turbo Upgrade with 1.9/2.0TDI Manifold

GTB2565VKLR with an estimated potential of 390-400HP at 38-40PSI.

Billet Wheel GTB2565VKLR Ceramic Ball Bearing Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2565VK with an estimated potential of 390-400HP at 38-40PSI.

Billet Wheel GTB2565VK Hybrid Turbo Upgrade vacuum converted with a welded 1.9/2.0 TDI Manifold

GTB2871VK with an estimated potential of 410-430HP at 39-41PSI.

Billet Wheel GTB2871VK Hybrid Turbo Upgrade vacuum converted 1.9/2.0 TDI

MFS GTB3073VKLR with an estimated potential of 500+HP at 40PSI.

MFS GTB3073VKLR Ball Bearing Big Turbo vacuum converted 1.9/2.0 TDI

And the best for last – MuchBoost GTB2060VKLR in action!
